ARO (Ingersoll Rand) Piston Pump SP0412T21FF47S22

SP0412T21FF47S22

ARO SP0412T21FF47S22 SPX Series Single-Post Ram Piston Pump Package. 4-1/4″ Motor, 12:1 Ratio, Container Suitability: 5 Gallon Container. Stainless Steel, UHMW-PE Upper & Lower Packing, Multiple Wave Spring, Hardened Stainless Steel w/Hard Chrome Plating Plunger. 1-1/2 – 11-1/2 NPTF -1 (Female) & 2 – 11-1/2 PTF SAE Short (Male) Inlet, 1 – 11-1/2 NPTF – 1 Outlet, 360 – 2085 psi (24.8 – 143.8 bar) Pressure Range.

Air Inlet 1/2 – 14 NPTF – 1
Build Single-Post Ram
CCN Number SP0412T21FF47S22
Discharge NPT (Inches) 1 – 11-1/2 NPTF – 1
Discharge Volume Per Cycle 12.5 In3
Includes Single-post ram with pump, follower plate, and controls
Inlet Pressure (PSI) 30 – 150 psi (2.1 – 10.3 bar)
Material Stainless Steel
Motor 4-1/4″
Mounting Type 5 Gallon Container
Options Advanced Ram and Pump Controls

Other Factors 6″ Stroke Length
Packing Gland UHMW-PE (Upper & Lower)
Pressure Range 360 – 2085 psi (24.8 – 143.8 bar)
Product Notes Hardened Stainless Steel w/Hard Chrome Plating Plunger
Quick Specs 5-GAL RAM PACKAGE, 1-POST, 4-1/4″, 12:1
Spring Multiple Wave Spring
Suction NPT (Inches) 1-1/2 – 11-1/2 NPTF -1 (Female) & 2 – 11-1/2 PTF SAE Short (Male)
Turn Down Ratio 12:1
Type Chop Check
