Atos Valve AGMZO-A-10/350 20 /PE

MAIN CHARACTERISTICS – based on mineral oil ISO VG46 at 50 °C
Assembly position
Any position
Roughness index, Ra 0,4 flatness ratio 0,01/100 (ISO 1101)
Subplate surface finishing
MTTFd valves according to EN ISO 13849
75 years, see technical table P007
A:
Ambient temperature range
standard = -20°C +70°C,
/BT option = -40°C +60°C
AEB, AES: standard = -20°C +60°C,
/BT option = -40°C +60°C
A:
standard = -20°C +80°C,
/BT option = -40°C +70°C
Storage temperature range
AEB, AES: standard = -20°C + +70°C,
/BT option = -40°C + +70°C
Standard = 3 + 3,3 Ω
Coil resistance R at 20°C
Option /6 = 2 + 2,2 Ω
Option /18 = 13 + 13,4Ω
Max. solenoid current
Standard = 2,6 A
Option /6 = 3,25 A
Option /18 = 1,5 A
Max. power
A = 30 Watt
AEB, AES = 50 Watt
Insulation class
H (180°) Due to the occuring surface temperatures of the solenoid coils, the European standards
ISO 13732-1 and EN982 must be taken into account
Protection degree to DIN EN60529
IP66/67 with mating connectors
Tropicalization (only AEB, AES)
Tropical coating on electronics PCB
Duty factor
Continuous rating (ED=100%)
EMC, climate and mechanical load
See technical table G004
USB
CANopen
PROFIBUS DP
EtherCAT
Communication interface (only REB, RES)
EN50170-2/IEC61158
Atos ASCII coding
EN50325-4 + DS408
IEC 61158
Communication physical layer
Fast Ethernet, insulated
not insulated
optical insulated
optical insulated
USB 2.0 + USB OTG
CAN ISQ11898
RS485
(only REB, RES)
100 Base TX
