Dayton Double Diaphragm Pump, Aluminum, Air Operated, Buna N, 50 GPM 22A594

Dimensions
Inlet/Outlet Size 1 1/4 in
Air Inlet Size 3/8 in FNPT
Height 17 1/4 in
Max. Dia. Solids 3/16 in
Width 11 1/4 in
Length 8 1/2 in
Manufacturers Warranty Length 1 yr
Overall Length 8.5 in
Overall Width 11.3 in
Overall Height 17.3 in
Solid Diameter (Maximum) 0.19 in
Air Intake Connection Size 3/8 in
Media Intake Connection Size 1 1/4 in
Media Discharge Connection Size 1 1/4 in
Details
Item Double Diaphragm Pump
Diaphragm Material Buna-N
Housing Material – Pumps Aluminum
Flow Rate (Maximum) 50 gpm
Diaphragm Material – Pumps Buna N
Valve Type Ball
Max. Flow 50 gpm
Item – Air Operated Pumps Double Diaphragm Pump
Pump Operation Type Air
Max. Temp – Pumps 180 Degrees F
Connection Style NPT
Max. Operating Pressure 100 psi
Max. Temp. 180 Degrees F
Manifold Connection Single Port
Self-Priming Wet 28 ft
Operation Type Air Operated
Self-Priming Dry 18 ft
Ball Material Buna N
Body Material Aluminum
Check Seat Material Aluminum
Max. Flow GPM 50 gpm
Includes Ball Valve
For Use With General Indsutrial Use Including Waste Oils, Water Based Chemicals and Fluids with A Neutral Ph. Handles Suspended Solids and Shear Sensative Fluids
Media Temperature (Maximum) 180 Degrees F
Duty Cycle Continuous
Flow Rate @ 30 psi 29 gpm
Wetted Housing Material Aluminum
Air Intake Pressure (Maximum) 100 psi
Non-Wetted Housing Material Aluminum
Operating Pressure (Maximum) 100 psi
Media Discharge Location Top
Air Intake Connection Type FNPT
Media Discharge Connection Type NPT
Flow Rate @ 70 psi 45 gpm
For Use With Potable Systems No
Media Intake Location Bottom
Pump Assembly Type Bolt
Flow Rate @ 60 psi 45 gpm
Media Temperature (Minimum) 0 Degrees F
Priming Self-Priming
Mounting Hardware Material Stainless Steel, Steel
Valve Material Buna-N
Air Consumption (Maximum) 55 scfm
Flow Rate @ 100 psi 50 gpm
Media Intake Connection Type FNPT
Viscosity (Maximum) 40,000 cps
Manifold Connection Type NPT
