Delta AC Fans GTW025FUC16

Additional information

brand	Delta
Model Number	GTW025FUC16
weight	Contact us for shipping weight
Description	AXIAL SQUARE 250MM L X 250MM H X
Data	Fan Motorized Impellers 230VAC Square – 253mm L x 253mm H Ball 1028.0 CFM (28.78m³/min) 3 Wire Leads with Ferrules, 7 Wire Leads with Ferrules

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Delta Electronics

Series
GTW

Packaging
Bulk

Part Status
Active

Voltage – Rated
230VAC

Size / Dimension
Square – 253mm L x 253mm H

Width
126.00mm

Air Flow
1028.0 CFM (28.78m³/min)

Static Pressure
1.575 in H2O (392.4 Pa)

Bearing Type
Ball

Fan Type
Motorized Impellers

Features
Electronic Commutation (EC), Locked Rotor Protection, PWM Control, Speed Sensor (Tach), Thermal Overload Protector (TOP)

Noise
76.5dB(A)

Power (Watts)
288W

RPM
3800 RPM
Termination
3 Wire Leads with Ferrules, 7 Wire Leads with Ferrules

Ingress Protection
IP54 – Dust Protected, Water Resistant

Operating Temperature
-13 ~ 140°F (-25 ~ 60°C)

Approval Agency
CE, cURus, TUV

Weight
–

Current Rating (Amps)
–

Voltage Range
200 ~ 277VAC

Material – Frame
Steel

Material – Blade
Plastic

Lifetime @ Temp.
60000 Hrs @ 40°C
