Delta DC Fans QFR1212EHE

US$235.12

Additional information

brand	Delta
Model Number	QFR1212EHE
weight	0.728 lb; 330.22 g
Description	FAN AXIAL 120X38MM 12VDC WIRE
Data	Fan Tubeaxial 12VDC Square – 120mm L x 120mm H Ball 173.8 CFM (4.87m³/min) 2 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Delta Electronics

Series
QFR

Packaging
Box

Part Status
Not For New Designs

Voltage – Rated
12VDC

Size / Dimension
Square – 120mm L x 120mm H

Width
38.00mm

Air Flow
173.8 CFM (4.87m³/min)

Static Pressure
0.844 in H2O (210.2 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Locked Rotor Protection

Noise
59.0dB(A)

Power (Watts)
12 W

RPM
5000 RPM
Termination
2 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 140°F (-10 ~ 60°C)

Approval Agency
CE, CSA, UL, VDE

Weight
0.728 lb (330.22 g)

Current Rating (Amps)
1.00A

Voltage Range
8 ~ 13.2VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
50000 Hrs @ 40°C

Base Product Number
QFR1212
