EBM-PAPST DC fan 8314HU-342

Additional information

brand	EBM-PAPST
Model Number	8314HU-342
weight	Contact us for shipping weight
Data	Fan Tubeaxial 48VDC Square – 80mm L x 80mm H Ball 39.5 CFM (1.11m³/min) 2 Wire Leads
Description	DC TUBEAXIAL FAN

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
ebm-papst Inc.

Series
8300U

Packaging
Bulk

Part Status
Active

Voltage – Rated
48VDC

Size / Dimension
Square – 80mm L x 80mm H

Width
32.00mm

Air Flow
39.5 CFM (1.11m³/min)

Static Pressure
–

Bearing Type
Ball

Fan Type
Tubeaxial

Features
–

Noise
43.0dB(A)

Power (Watts)
4.3 W

RPM
4200 RPM
Termination
2 Wire Leads

Ingress Protection
–

Operating Temperature
-4 ~ 167°F (-20 ~ 75°C)

Approval Agency
CSA, CE, VDE, UL

Weight
–

Current Rating (Amps)
–

Voltage Range
36 ~ 56VDC

Material – Frame
Polybutylene Terephthalate (PBT), Fiberglass Reinforced

Material – Blade
Polyamide (PA), Nylon, Fiberglass Reinforced

Lifetime @ Temp.
Varies Based on Temperature
