Mechatronics AC Fans LPH12A99-BTLR

Additional information

brand	Mechatronics
Model Number	LPH12A99-BTLR
weight	0.631 lb (286.20 g)
Description	FAN AXIAL 120X38MM 100/240VAC
Data	Fan Tubeaxial 100 ~ 240VAC Square – 120mm L x 120mm H Ball 86.0 CFM (2.41m³/min) 2 Terminals

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Mechatronics Fan Group

Series
LPH12A99

Packaging
Bulk

Part Status
Active

Voltage – Rated
100 ~ 240VAC

Size / Dimension
Square – 120mm L x 120mm H

Width
38.50mm

Air Flow
86.0 CFM (2.41m³/min)

Static Pressure
0.200 in H2O (49.8 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart, Electronic Commutation (EC)

Noise
39.0dB(A)

Power (Watts)
4.20W

RPM
2500 RPM
Termination
2 Terminals

Ingress Protection
–

Operating Temperature
–

Approval Agency
–

Weight

0.631 lb (286.20 g)

Current Rating (Amps)
0.080A

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
50000 Hrs @ 25°C

Base Product Number
LPH12
