Mechatronics AC Fans UF17PC23-BTLR

Additional information

brand	Mechatronics
Model Number	UF17PC23-BTLR
weight	1.8 lbs (816.5 g)
Description	FAN AXIAL 172X51MM 230VAC TERM
Data	Fan Tubeaxial 230VAC Round – 172mm Dia Ball 106.0 CFM (2.97m³/min) 2 Terminals

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Mechatronics Fan Group

Series
UF17PC

Packaging
Bulk

Part Status
Active

Voltage – Rated
230VAC

Size / Dimension
Round – 172mm Dia

Width
51.00mm

Air Flow
106.0 CFM (2.97m³/min)

Static Pressure
0.220 in H2O (54.8 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)

Noise
37.0dB(A)

Power (Watts)
29.00W

RPM
1700 RPM
Termination
2 Terminals

Ingress Protection
–

Operating Temperature
-40 ~ 158°F (-40 ~ 70°C)

Approval Agency
CE, cUL, TUV, UL

Weight

1.8 lbs (816.5 g)

Current Rating (Amps)
0.070A

Voltage Range
–

Material – Frame
Aluminum

Material – Blade
Polybutylene Terephthalate (PBT)

Base Product Number
UF17P
