Mechatronics DC Fans MS9238M48B1+6-FHR-2EM

Additional information

brand	Mechatronics
Model Number	MS9238M48B1+6-FHR-2EM
weight	0.446 lb (202.3 g)
Description	FAN AXIAL 92X38MM 48VDC WIRE
Data	Fan Tubeaxial 48VDC Square – 92mm L x 92mm H Ball 125.3 CFM (3.51m³/min) 4 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL

Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Mechatronics Fan Group

Series
MS9238-H

Packaging
Bulk

Part Status
Active

Voltage – Rated
48VDC

Size / Dimension
Square – 92mm L x 92mm H

Width
38.00mm

Air Flow
125.3 CFM (3.51m³/min)

Static Pressure
0.870 in H2O (216.7 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart, PWM Control, Speed Sensor (Tach)

Noise
56.0dB(A)

RPM
6000 RPM

Termination
4 Wire Leads

Ingress Protection
IP68 – Dust Tight, Waterproof

Operating Temperature
–

Approval Agency
–

Weight

0.446 lb (202.3 g)

Current Rating (Amps)
0.230A

Voltage Range
–

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
–

Base Product Number
MS9238
