NMB AC fan 04010SA-24N-ALD-0

Additional information

brand	NMB
Model Number	04010SA-24N-ALD-0
weight	Contact us for shipping weight
Description	FAN 24VDC 40X10MM LOCK ROTOR
Data	Fan Tubeaxial 24VDC Square – 40mm L x 40mm H Ball 6.8 CFM (0.190m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
NMB Technologies Corporation

Series
04010SA

Packaging
Box

Part Status
Active

Voltage – Rated
24VDC

Size / Dimension
Square – 40mm L x 40mm H

Width
10.00mm

Air Flow
6.8 CFM (0.190m³/min)

Static Pressure
0.201 in H2O (50.0 Pa)

Bearing Ball

Fan Tubeaxial

Features
Auto Restart, Locked Rotor Sensor

Noise
29.5dB(A)

Power (Watts)
0.96 W

RPM
7500 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 158°F (-10 ~ 70°C)

Approval Agency
–

Weight
–

Current Rating (Amps)
0.060A

Voltage Range
20 ~ 26.4V

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.

30000 Hrs @ 40°C
