NMB AC fan 04056EA-12R-EUB-02

Additional information

brand	NMB
Model Number	04056EA-12R-EUB-02
weight	Contact us for shipping weight
Description	FAN AXIAL DUAL 40X56MM 12VDC
Data	Fan Tubeaxial (Dual) 12VDC Square – 40mm L x 40mm H Ball 30.3 CFM (0.848m³/min) 4 Wire Leads per Fan

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
NMB Technologies Corporation

Series
04056EA

Packaging
Box

Part Status
Active

Voltage – Rated
12VDC

Size / Dimension
Square – 40mm L x 40mm H

Width
56.00mm

Air Flow
30.3 CFM (0.848m³/min)

Static Pressure
3.100 in H2O (772.2 Pa)

Bearing Ball

Fan Tubeaxial (Dual)

Features
Auto Restart, PWM Control, Speed Sensor (Tach)

Noise
69.0dB

Power (Watts)
15.6 W

RPM
20000 Front, 18000 Rear

Termination
4 Wire Leads per Fan

Ingress Protection
–

Operating Temperature
14 ~ 140°F (-10 ~ 60°C)

Approval Agency
CE, cULus, VDE

Weight
–

Current Rating (Amps)
1.30A

Voltage Range
10.8 ~ 12.6VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.

70000 Hrs @ 40°C

Base Product Number
04056EA
