NMB AC fan 4715KL-05W-B59-R00

US$21.36

Additional information

brand	NMB
Model Number	4715KL-05W-B59-R00
weight	0.573 lb; 259.91 g
Description	FAN AXIAL 119X38.4MM 24VDC WIRE
Data	Fan Tubeaxial 24VDC Square – 119mm L x 119mm H Ball 130.0 CFM (3.64m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
NMB Technologies Corporation

Series
11938KA

Packaging
Box

Part Status
Obsolete

Voltage – Rated
24VDC

Size / Dimension
Square – 119mm L x 119mm H

Width
38.40mm

Air Flow
130.0 CFM (3.64m³/min)

Static Pressure
0.441 in H2O (110.0 Pa)

Bearing Ball

Fan Tubeaxial

Features
Locked Rotor Sensor

Noise
50.0dB

Power (Watts)
12 W

RPM
3600 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 104°F (-10 ~ 40°C)

Approval Agency
CE, CSA, UL, VDE

Weight
0.573 lb (259.91 g)

Current Rating (Amps)
0.5A

Voltage Range
18 ~ 25VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.

100000 Hrs @ 25°C
