Orion AC fans OA2543AN-11-1TB1856

Additional information

brand	Orion
Model Number	OA2543AN-11-1TB1856
weight	4.6 lb;s 2.1 kg
Data	Fan Tubeaxial 115VAC Round – 254mm Dia Ball 930.0 CFM (26.04m³/min) 2 Terminals
Description	FAN AXIAL 254X89MM 115VAC TERM

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Orion Fans

Series
OA2543AN

Packaging
Box

Part Status
Active

Voltage – Rated
115VAC

Size / Dimension
Round – 254mm Dia

Width
89.00mm

Air Flow
930.0 CFM (26.04m³/min)

Static Pressure
1.070 in H2O (266.5 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Capacitor, Thermal Overload Protector (TOP)

Noise
67.0dB

Power (Watts)
105W

RPM
3300 RPM
Termination
2 Terminals

Ingress Protection
IP56 – Dust Protected, Water Resistant

Operating Temperature
-22 ~ 176°F (-30 ~ 80°C)

Approval Agency
cURus, TUV

Weight

4.6 lbs (2.1 kg)

Current Rating (Amps)
–

Voltage Range
100 ~ 120VAC

Material – Frame
Aluminum

Material – Blade
Metal

Lifetime @ Temp.
50000 Hrs @ 55°C

Base Product Number
OA2543AN
