Orion AC fans OA60EC-UR-1WBIP68A

Additional information

brand	Orion
Model Number	OA60EC-UR-1WBIP68A
weight	0.133 lb; 60.33 g
Data	Fan Tubeaxial 95 ~ 264VAC Square – 60mm L x 60mm H Ball 19.5 CFM (0.546m³/min) 2 Wire Leads
Description	FAN EC 60X25MM 95-264VAC IP68 AT

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Orion Fans

Series
OA60EC

Packaging
Box

Part Status
Active

Voltage – Rated
95 ~ 264VAC

Size / Dimension
Square – 60mm L x 60mm H

Width
25.00mm

Air Flow
19.5 CFM (0.546m³/min)

Static Pressure
0.170 in H2O (42.3 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Electronic Commutation (EC), Thermal Overload Protector (TOP)

Noise
31.0dB

Power (Watts)
2.40W

RPM
3950 RPM
Termination
2 Wire Leads

Ingress Protection
IP68 – Dust Tight, Waterproof

Operating Temperature
-4 ~ 158°F (-20 ~ 70°C)

Approval Agency
ATEX, CE, cURus, UR

Weight

0.133 lb (60.33 g)

Current Rating (Amps)
0.050A

Voltage Range
–

Material – Frame
Polybutylene Terephthalate (PBT)

Material – Blade
Polybutylene Terephthalate (PBT)

Lifetime @ Temp.
50000 Hrs @ 40°C

Base Product Number
OA60EC
