Orion DC fans OD1238-48HHBXC

Additional information

brand	Orion
Model Number	OD1238-48HHBXC
weight	Contact us for shipping weight
Data	Fan Tubeaxial 48VDC Square – 120mm L x 120mm H Ball 220.0 CFM (6.16m³/min) 2 Wire Leads
Description	FAN AXIAL 120X38.5MM 48VDC WIRE

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Orion Fans

Series
OD1238 XC

Packaging
Bulk

Part Status
Active

Voltage – Rated
48VDC

Size / Dimension
Square – 120mm L x 120mm H

Width
38.50mm

Air Flow
220.0 CFM (6.16m³/min)

Static Pressure
0.750 in H2O (186.8 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart

Noise
63.0dB

Power (Watts)
32 W

RPM
4700 RPM
Termination
2 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 158°F (-10 ~ 70°C)

Approval Agency
cURus, TUV

Weight

–

Current Rating (Amps)
0.680A

Voltage Range
–

Material – Frame
Polybutylene Terephthalate (PBT), Fiberglass Reinforced

Material – Blade
Polybutylene Terephthalate (PBT), Fiberglass Reinforced

Lifetime @ Temp.
65000 Hrs @ 45°C

Base Product Number
OD1238
