Orion DC fans OD4015-24HB02A

Additional information

brand	Orion
Model Number	OD4015-24HB02A
weight	Contact us for shipping weight
Data	Fan Tubeaxial 24VDC Square – 40mm L x 40mm H Ball 8.5 CFM (0.238m³/min) 3 Wire Leads
Description	FAN AXIAL 40X15MM 24VDC WIRE

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Orion Fans

Series
OD4015

Packaging
Box

Part Status
Active

Voltage – Rated
24VDC

Size / Dimension
Square – 40mm L x 40mm H

Width
15.00mm

Air Flow
8.5 CFM (0.238m³/min)

Static Pressure
0.250 in H2O (62.3 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart, Locked Rotor Sensor

Noise
36.0dB

Power (Watts)
1.92 W

RPM
8000 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 158°F (-10 ~ 70°C)

Approval Agency
CE, cURus

Weight

–

Current Rating (Amps)
0.060A

Voltage Range
17 ~ 26.4VDC

Material – Frame
Polybutylene Terephthalate (PBT)

Material – Blade
Polybutylene Terephthalate (PBT)

Lifetime @ Temp.
70000 Hrs @ 40°C

Base Product Number
OD4015
