Sandpiper Air Operated Diaphragm Pump, 40 scfm T1FB1SASWTS600.

Dimensions
Manufacturers Warranty Length 5 yr
Overall Height 14 in
Solid Diameter (Maximum) 0.25 in
Overall Length 10.3 in
Air Intake Connection Size 1/2 in
Media Discharge Connection Size 1 1/2 in
Media Intake Connection Size 1 1/2 in
Overall Width 12.5 in
Details
Pump Operation Type Air
Diaphragm Material PTFE
Check Seat Material Stainless Steel
Manifold Connection Single Port
Item Air Operated Double Diaphragm Pump
Standards CE Certified, EC 1935, FDA Compliant, ISO
Valve Type Ball
Flow Rate @ 60 psi 42.5 gpm
Flow Rate @ 40 psi 37 gpm
Media Intake Connection Type Tri-Clamp
Media Discharge Location Top
Media Discharge Connection Type Tri-Clamp
Series Family T
Flow Rate @ 80 psi 45 gpm
Air Intake Connection Type NPT
Priming Self-Priming
Series T1F
Flow Rate (Maximum) 45 gpm
Wetted Housing Material 316 Stainless Steel
Media Temperature (Maximum) 190 Degrees F
Non-Wetted Housing Material Aluminum
Mounting Hardware Material Stainless Steel
Pump Assembly Type Bolt
Flow Rate @ 100 psi 45 gpm
Operating Pressure (Maximum) 125 psi
Media Intake Location Bottom
Flow Rate @ 20 psi 28 gpm
Air Consumption (Maximum) 40 scfm
Valve Material PTFE
Feet of Head (Maximum) 289 ft
