Sanyo Fan 9EC2048A001

1.8 kg

Additional information

brand	Sanyo
Model Number	9EC2048A001
weight	3.9 lbs; 1.8 kg
Description	FAN AXIAL 200X70MM 48VDC WIRE
Specification	Fan Tubeaxial 48VDC Round – 200mm Dia Ball 519.0 CFM (14.53m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sanyo Denki America Inc.

Series
San Ace 200

Packaging
Box

Part Status
Active

Voltage – Rated
48VDC

Size / Dimension
Round – 200mm Dia

Width
70.00mm

Air Flow
519.0 CFM (14.53m³/min)

Static Pressure
2.570 in H2O (640.1 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Locked Rotor Protection, Speed Sensor (Tach)

Noise
68.0dB(A)

Power (Watts)
105.6 W

RPM
4800 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
-4 ~ 140°F (-20 ~ 60°C)

Approval Agency
CSA, TUV, UL

Weight
3.9 lbs (1.8 kg)

Current Rating (Amps)
2.20A

Voltage Range
43 ~ 51VDC

Material – Frame
Aluminum

Material – Blade
Plastic

Lifetime @ Temp.
40000 Hrs @ 60°C

Base Product Number
9EC2048
