Sanyo Fan 9G0912H1D01

US$86.80

Additional information

brand	Sanyo
Model Number	9G0912H1D01
weight	0.397 lb (180.08 g)
Description	FAN AXIAL 92X38MM 12VDC WIRE
Specification	Fan Tubeaxial 12VDC Square – 92mm L x 92mm H Ball 90.0 CFM (2.52m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sanyo Denki America Inc.

Series
San Ace 92

Packaging
Box

Part Status
Active

Voltage – Rated
12VDC

Size / Dimension
Square – 92mm L x 92mm H

Width
38.00mm

Air Flow
90.0 CFM (2.52m³/min)

Static Pressure
0.402 in H2O (100.1 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Locked Rotor Sensor

Noise
43.0dB(A)

Power (Watts)
6.96 W

RPM
4000 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
-4 ~ 140°F (-20 ~ 60°C)

Approval Agency
CSA, TUV, UL

Weight
0.397 lb (180.08 g)

Current Rating (Amps)
0.580A

Voltage Range
7 ~ 13.8VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
40000 Hrs @ 60°C

Base Product Number
9G0912
