Sanyo Fan 9GV1248H401

US$125.32

Additional information

brand	Sanyo
Model Number	9GV1248H401
weight	0.573 lb; 260.00 g
Description	FAN AXIAL 120X25.4MM 48VDC WIRE
Specification	Fan Tubeaxial 48VDC Square – 120mm L x 120mm H Ball 154.0 CFM (4.31m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sanyo Denki America Inc.

Series
San Ace 120

Packaging
Box

Part Status
Active

Voltage – Rated
48VDC

Size / Dimension
Square – 120mm L x 120mm H

Width
25.40mm

Air Flow
154.0 CFM (4.31m³/min)

Static Pressure
0.730 in H2O (181.8 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Locked Rotor Protection, Speed Sensor (Tach)

Noise
55.0dB(A)

Power (Watts)
15.84 W

RPM
4600 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
-4 ~ 158°F (-20 ~ 70°C)

Approval Agency
CSA, TUV, UL

Weight
0.573 lb (260.00 g)

Current Rating (Amps)
0.330A

Voltage Range
40.8 ~ 60VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
40000 Hrs @ 60°C

Base Product Number
9GV1248
