Sanyo Fan 9WF0424H7D01

US$16.84

Additional information

brand	Sanyo
Model Number	9WF0424H7D01
weight	0.077 lb; 34.93 g
Description	FAN AXIAL 40X15MM 24VDC WIRE
Specification	Fan Tubeaxial 24VDC Square – 40mm L x 40mm H Ball 6.9 CFM (0.193m³/min) 3 Wire Leads

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION
SELECT ALL
Category

Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sanyo Denki America Inc.

Series
San Ace 40WF

Packaging
Box

Part Status
Active

Voltage – Rated
24VDC

Size / Dimension
Square – 40mm L x 40mm H

Width
15.00mm

Air Flow
6.9 CFM (0.193m³/min)

Static Pressure
0.320 in H2O (79.7 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Locked Rotor Sensor

Noise
38.0dB(A)

Power (Watts)
2.04 W

RPM
11300 RPM
Termination
3 Wire Leads

Ingress Protection
Oil Resistant

Operating Temperature
-4 ~ 158°F (-20 ~ 70°C)

Approval Agency
CSA, TUV, UL

Weight
0.077 lb (34.93 g)

Current Rating (Amps)
0.085A

Voltage Range
20.4 ~ 27.6VDC

Material – Frame
Plastic

Material – Blade
Plastic

Lifetime @ Temp.
40000 Hrs @ 60°C

Base Product Number
9WF0424
