Sunon AC Fans CF4113HBL-000U-AED

US$29.20

Additional information

brand	Sunon
Model Number	CF4113HBL-000U-AED
weight	0.699 lb (317.06 g)
Data	Fan Tubeaxial 100/240VAC Square – 120mm L x 120mm H Ball 109.0 CFM (3.05m³/min) 2 Wire Leads
Description	FAN AXIAL 120X38MM 100/240VAC

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
AC Fans

Manufacturer
Sunon Fans

Series
CF

Packaging
Bulk

Part Status
Active

Voltage – Rated
100/240VAC

Size / Dimension
Square – 120mm L x 120mm H

Width
38.00mm

Air Flow
109.0 CFM (3.05m³/min)

Static Pressure
0.370 in H2O (92.2 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart, Dual Voltage, Electronic Commutation (EC)

Noise
44.9dB(A)

Power (Watts)
5.10W

RPM
3500 RPM
Termination
2 Wire Leads

Ingress Protection
IP68 – Dust Tight, Waterproof

Operating Temperature
-13 ~ 158°F (-25 ~ 70°C)

Approval Agency
ATEX, CE, CUR, TUV, UL

Weight
0.699 lb (317.06 g)

Current Rating (Amps)
0.081A

Voltage Range
90 ~ 265VAC

Material – Frame
Polybutylene Terephthalate (PBT)

Material – Blade
Polybutylene Terephthalate (PBT)

Lifetime @ Temp.
–

Base Product Number
CF4113HBL
