Sunon DC Fans B0503AFB2-8 MS

US$4.06

Additional information

brand	Sunon
Model Number	B0503AFB2-8 MS
weight	0.023 lb; 10.43 g
Data	Fan Blower 5VDC Square – 30mm L x 30mm H Ball 1.1 CFM (0.031m³/min) 2 Wire Leads
Description	FAN BLOWER 30X10MM 5VDC WIRE

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sunon Fans

Series
–

Part Status
Obsolete

Voltage – Rated
5VDC

Size / Dimension
Square – 30mm L x 30mm H

Width
10.00mm

Air Flow
1.1 CFM (0.031m³/min)

Static Pressure
0.260 in H2O (64.8 Pa)

Bearing Type
Ball

Fan Type
Blower

Features
–

Noise
30.0dB(A)

Power (Watts)
650 mW

RPM
8000 RPM
Termination
2 Wire Leads

Ingress Protection
–

Operating Temperature
–

Approval Agency
–

Weight
0.023 lb (10.43 g)

Current Rating (Amps)
0.130A

Voltage Range
–

Material – Frame
–

Material – Blade
–

Lifetime @ Temp.
–
