Sunon DC Fans PF40281B1-000U-G99

Sunon DC Fans PF40281B1-000U-G99

US$16.41

Additional information

brand	Sunon
Model Number	PF40281B1-000U-G99
weight	0.093 lb (42.18 g)
Data	Fan Tubeaxial 12VDC Square – 40mm L x 40mm H Ball 24.9 CFM (0.697m³/min) 3 Wire Leads
Description	FAN AXIAL 40X28MM 12VDC WIRE

Condition: 100% new condition.
Availability: 12 units in stock in the warehouse.
Delivery time: 3-7 workdays after confirm your payment.
MOQ: 1 unit.
Payment term: 100% in advance by T/T, PayPal, Stripe, Credit Card or Western Union in USD.
Warranty: 1 year.
Shipping cost: The price not include freight cost. To confirm the specific freight cost, please contact us with the quantity and receiving address.
Packaging Method: Standard export and import packaging for free, plywood wooden cases or cartons.
Online support: 24-hour online customer service.
Refund term: 30 days money back guarantee.

TYPE

DESCRIPTION

SELECT ALL
Category
Fans, Blowers, Thermal Management
Fans
DC Brushless Fans (BLDC)

Mfr
Sunon Fans

Series
PF

Packaging
Bulk

Part Status
Obsolete

Voltage – Rated
12VDC

Size / Dimension
Square – 40mm L x 40mm H

Width
28.00mm

Air Flow
24.9 CFM (0.697m³/min)

Static Pressure
1.950 in H2O (485.7 Pa)

Bearing Type
Ball

Fan Type
Tubeaxial

Features
Auto Restart, Speed Sensor (Tach)

Noise
56.0dB(A)

Power (Watts)
6.12 W

RPM
17600 RPM
Termination
3 Wire Leads

Ingress Protection
–

Operating Temperature
14 ~ 158°F (-10 ~ 70°C)

Approval Agency
CE, CUR, TUV, UL

Weight
0.093 lb (42.18 g)

Current Rating (Amps)
0.510A

Voltage Range
6.5 ~ 13.2VDC

Material – Frame
Polybutylene Terephthalate (PBT)

Material – Blade
Polybutylene Terephthalate (PBT)

Lifetime @ Temp.
70000 Hrs @ 40°C

Base Product Number
PF40281B1
