Wilden Diaphragm Pump A.025P/SZPPP/TNL/TF/STV/0160

00-10094

Wilden 00-10094 Accu-Flo Electronic Control 1/4″ Clamped Metal Air Operated Double Diaphragm Pump (A.025P), MODEL: A.025P/SZPPP/TNL/TF/STV/0160. 15.1 lpm (4 gpm) Max Flow, 6 mm (1/4″) BSPT Suction & Discharge. Stainless Steel Wetted Parts & Seats, Polypropylene Air Chamber, Center Block & Air Valve, PTFE-Encapsulated FKM O-Rings, PTFE w/Neoprene Backup Reduced-Stroke IPD Diaphragm, PTFE Balls. A PSG Dover Brand Product.

Air Chamber Polypropylene
Air Distribution System Accu‑Flo w/ Pro‑Flo Base
Air Inlet 1/8″ FNPT
Center Block Polypropylene
Connection Type BSPT
Construction Clamped
Diaphragm PTFE w/Neoprene Backup O-Ring
Diaphragm Type Reduced-Stroke IPD
Discharge NPT (Inches) 6 mm (1/4″)
Discharge Volume Per Cycle 0.02 L (0.005 gal)
Material Metal
Maximum Flow (GPM) 15.1 lpm (4 gpm)
Maximum Working Pressure (PSIG) 8.6 bar (125 psi)

Max Suction Lift 3.80 m (12.5′) Dry, 9.33 m (30.6′) Wet
Model Number A.025P/SZPPP/TNL/TF/STV/0160
Model Series A.025P
Outer Piston No Outer Piston
Size 1/4″
Solids (Inches) 0.4 mm (1/64″)
Special Configuration 0160 Accu-Flo, 24V DC coil, BSPT
Suction NPT (Inches) 6 mm (1/4″)
Valve Balls PTFE
Valve / Seat / O-Ring Polypropylene Air Valve / Stainless Steel Seat / PTFE-Encapsulated FKM O-Rings
Valve Type Ball Valve
Wetted Parts Stainless Steel
